Best Graphics Settings Guide

UPDATE – Terrain Level of Detal value has been lowered to 150 for a much more stutter-free flying. Virtual Memory section of the article updated. Enable Rolling Cache only if using Photogrammetry, otherwise disable and delete it. Note that do not use any of the tree or season mods making trees shorter, it will downgrade the autogen trees draw distance significantly. Be sure to check our updated Performance Boost Tricks as well.

This is a set-up guide for the best graphics without losing too much performance of the Microsoft Flight Simulator. My kinda solid frames-per-second value increased noticeably, and I still maintained very good-looking visuals and terrain detail, almost no difference compared all set to Ultra. There’s no need to max out all the settings, instead enjoy a lot smoother flying experience due to better performance after these settings. Of course, the benefit is tied to what kind of system you are running MSFS in, and the effect might change by future MSFS patches and optimizations by Asobo Studio. The hardware used for this article is Intel Core i7-9750, RTX 2060 6GB, 16GB RAM, and 512GB SSD.

Ensure your system is up-to-date, meaning your Windows 10 or 11 has all the latest updates installed. Open Start menu, select Settings – Update & Security – Windows Update – Check for updates. Also, ensure that all the apps are up-to-date in Microsoft Store. In the bottom left-hand side corner of the Microsoft Store window, click on the Library option, then on the top right-hand side of the window, click Get updates, and install all the available updates. I do recommend turning automatic updates OFF for both Windows 10 or 11 and Microsoft Store. Updates rolling on the background can interfere with the performance of MSFS.

Ensure your Graphics Processing Unit has the best driver installed. Too outdated or sometimes the newest graphics driver can impact the performance of MSFS. We will inform in here if there’s a specific driver version recommendation. Go get the official graphics card driver for your GeForce or Radeon graphics card. Note that the GeForce Experience app can change the MSFS graphic settings without user notice. Disable this feature by unchecking the Automatically optimize newly added games under the GFE’s Optimal playable settings. Also, it’s important to disable CPU/GPU overclocking while running the MSFS, it can cause random crash-to-desktop issues.

Next, let’s tweak a couple of settings on Windows 10 or 11 before launching the MSFS. With the Game Mode enabled, which should usually prioritize games and minimize background tasks to improve performance, many games encounter poorer frame rates, stutters, and freezes. Therefore, open the Start menu, select Settings, for Find a setting field type Game Mode, and under its settings turn Game Mode OFF. On the same page under the Related settings title, click on Graphics settings and make sure Hardware-accelerated GPU scheduling, aka HAGS, is OFF. Also, under Captures settings (found by Find a setting field), make sure Background recording is OFF.

Setting the Virtual Memory manually can help to end unknown crash-to-desktop issues and prevent stutters. In the Windows Search bar, type and open View advanced system settings. Under the Advanced tab, click the Settings (Performance). On the Performance Options, go to the Advanced tab and set Processor scheduling to Background services (and Apply), which after, click Change (Virtual memory). Uncheck the Automatically manage paging file size for all drives. Click to select the drive on which Windows 10 or 11 is installed (by default C:). Select the Custom size and for Initial size set 49152 MB and for Maximum size set 49152 MB. If having 32GB RAM installed or more, select System managed size instead. Finally, click Set, then click OK, and restart your computer.

Finally, it’s time to tweak the Microsoft Flight Simulator graphics settings in-game under GENERAL OPTIONS. Several settings have a high impact on performance but by setting them right you gain a smoother flight simulator and still maintain very good-looking visuals and the best terrain details. At first, set the Display Mode to FULL SCREEN, and make sure the Full Screen Resolution is your native resolution. Even though your monitor might support 4K, it can have a high frames-per-second impact, so we prefer to use Full HD resolution 1920X1080. Reset the in-sim graphics settings first by selecting the Global Rendering Quality to be HIGH-END and then check that the rest of the options are as described below.

Render Scaling: 100
V-Sync: OFF
DirectX Version: DX11
Anti-Aliasing: TAA
Terrain Level of Detail: 150
Off Screen Terrain Pre-Caching: ULTRA
Terrain Vector Data: ULTRA
Buildings: ULTRA
Trees: ULTRA
Grass and Bushes: ULTRA
Object Level of Detail: 200
Volumetric Clouds: HIGH
Texture Resolution: HIGH
Anisotropic Filtering: 16X
Texture Supersampling: 6X6
Texture Synthesis: HIGH

Water Waves: HIGH
Shadow Maps: 1536
Terrain Shadows: 512
Contact Shadows: HIGH
Windshield Effects: HIGH
Ambient Occlusion: HIGH
Cubemap Reflections: 192
Raymarched Reflections: HIGH
Light Shafts: HIGH
Bloom: ON
Depth of Field: OFF
Motion Blur: OFF
Lens Correction: OFF
Lens Flare: OFF
Glass Cockpit Refresh Rate: MEDIUM

If flying online on networks such as VATSIM, note that under the TRAFFIC page, the Ground Aircraft Density controls the amount of static aircraft at the gates, set this to zero. The other values under the TRAFFIC page should not be more than a value of 50 either. If your Internet connection is slower than 50 Mbps or experiencing heavy stutters even though not flying near any photogrammetry area, disable Photogrammetry under the DATA page. Enable Rolling Cache minimum of 8 GB only if using Photogrammetry, otherwise disable and delete it. With graphics settings explained in this guide, my FPS is pretty much solid 35, with the FPS limit set to 35. Next, check our Performance Boost Tricks to deal with most of the stutters left.
